JEEP WRANGLER JL, JLU, JK, JKU & JT GLADIATOR FRONT WINCH BUMPER

High Clearance, Military Inspired, Ultra High Strength Front Bumper for the Wrangler JK/JKU, JL/JLU and Gladiator JT. Features: ¼” Steel Construction. Precision Laser Cut and CNC Bent. Deeply Recessed Winch Mounting Location for efficient vehicle cooling. Two Front Hi-Lift Jack Points Integrated In. 2” of gained front ground clearance for increased approach angle. Narrow width to effectively clear large tires at full turn and articulation. Proudly Made in the USA

2012-2018 Jeep Wrangler JKs will require EVO-1096 Vacuum Pump Relocation Kit in addition  not included

When optioned with Dring or Stinger. This bumper combo is often used for flat tow/ tow bar. Consult your tow bar manufacturer for applications/ratings. 3/4” tabs with 1” pin/hole

Jeep Mojave vehicle will require installer to relocate Shock reservoirs no provisions are provided to achieve this

Steel 1/4 Pounder weight is approximately 70 lbs

Aluminum 1/4 Pounder Weight is approximately 40 lbs

Fits all Stamdard winches like Warn Zeon, Warn EVO etc  Typical 10″ x 4.5″ bolt pattern on bottom face.

Powdercoated bumpers are offered as a convenience. We do not cover finish/powdercoating under warranty. All our bumper/tire Carrier products are also available in raw metal for local treatment specific to your area needs.

*** Vehicle variances, part variances and winch model variances may require additional bumper spacing.  They are available separately on EVO website with part number EVO-10037B.  Use additional as needed
